Brochure
MAINLY USED IN
Mining/Quarry
General Construction
-
OPERATING WEIGHT
17.2 ton
-
BUCKET CAPACITY (SAE HEAPED)
3.2 m³
-
ENGINE POWER (SAE J1995 GROSS)
162 kW @2,000 rpm
Specifications
| Classification | SD320A |
|---|---|
| Operating Weight | 17.2 ton |
| Bucket Capacity (SAE HEAPED) | 3.2 m³ |
| Engine Power (SAE J1995 Gross) | 162 kW @2,000 rpm |
| Engine Model | Weichai WD10G220E23 (TIER 2) |
| Height at Bucket Pivot Point | 4,150 mm |
| Breakout Force | 16.5 kN |
| Turning Radius at Tire Center | 5,950 mm |
| Tires | 23.5-25-16 PR |
| Overall Length | 8,150 mm |
| Overall Width | 2,992 mm |
| Overall Height | 3,520 mm |
| Static Tipping Load(straight) | 13,200 kg |
Compare
Products
Products
| Classification |
|---|
| Operating Weight |
| Bucket Capacity (SAE HEAPED) |
| Engine Power (SAE J1995 Gross) |
| Engine Model |
| Height at Bucket Pivot Point |
| Breakout Force |
| Turning Radius at Tire Center |
| Tires |
| Overall Length |
| Overall Width |
| Overall Height |
| Static Tipping Load(straight) |
| SD320A |
|---|
| 17.2 ton |
| 3.2 m³ |
| 162 kW @2,000 rpm |
| Weichai WD10G220E23 (TIER 2) |
| 4,150 mm |
| 16.5 kN |
| 5,950 mm |
| 23.5-25-16 PR |
| 8,150 mm |
| 2,992 mm |
| 3,520 mm |
| 13,200 kg |
